24V | 16W/m RGB+3K | IP20 | COB Flexible LED Strip Light

24V | 16W/m RGB+3K | IP20 | COB Flexible LED Strip Light


Lighting Creations

In stock

The use of COB technology means the visible dots are almost eliminated.  This gives the added advantage of not requiring a profile and lens to diffuse the unsightly dots.

COB flexible strip light offers a seamless visual linear light, eliminating any visual dots often found with traditional strip light.  Ideal for installations where the LED strip will not be mounted within profile but seen.

This PCB is made using 3oz copper, this reduces voltage drop, so allows for a continuous 10m length without visible loss of brightness.

This LED strip carries an IP rating of 20, this is an indoor / dry environment LED strip only.

  • Requires 24V driver (sold separately)
  • Choose from a range of drivers between 60W and 200W to match the length of flexi-strip required
  • Remote, wall mounted and CONNECT Wi-Fi controllers available as accessories
  • For runs over 5m individual lengths should be connected in parallel
  • Easy clip connector packs available as accessories


Electrical Data
Voltage 24 VDC
Wattage 1m 16 W
Current 1m 1.26 A
LED Data
Package Type COB
Chips LED N/A
Chips 1m 840
Photometric Data
Colour Temperature RGB (Red, Green, Blue) + 3000K
Colour Rendering Index Ra N/A
Luminous Flux 1m N/A
Luminous Efficacey N/A
Beam Angle 120°
Dimmable 1 ∼ 100% (refer data sheet)
Construction / Protection Data
Substrate Double layer FPCB
Mounting Double sided tape 3M 9080
IP Rating IP20
Operating Temperature -20 ∼ +70 C°
Storage Temperature -20 ∼ +50 C°
Cutting increments 50.0mm
Length 5m (Priced per meter)
Width 10.0mm
Height 5.0mm
Working Life 70,0000 hrs
